Introduction
As the leading manufacturer of phenolic resins in the country, Shengquan has consistently dedicated itself to the development and application of these resins, continuously enhancing their various properties. Its exceptional overall performance has garnered global recognition from customers.
Specification
| Grade | Cure Time (s/150℃) | Pellet Flow (mm/125c) | Hexa Content (%) | Free Phenol (%) | Feature | Type | |
| PF-6815A | 80-95 | 43-57 | 8.5-9.5 | <1.0 | Good Adhesion | Pure Phenolic Resin | |
| PF-6076C | 65-95 | 35-55 | 6.5-7.5 | 2.0-3.5 | Good Adhesion | Pure Phenolic Resin | |
| PF-6816 | 70-95 | 35-50 | 8.5-9.5 | <1.5 | Good Adhesion | Pure Phenolic Resin | |
| PF-6290A | 50-90 | 30-55 | 6.5-7.5 | 2.0-4.0 | Good Flexibility | CNSL Modified Phenolic Resin | |
| PF-6291A | 40-70 | 25-40 | 9.0-10.0 | 2.0-4.0 | Good Flexibility | CNSL Modified Phenolic Resin | |
| PF-6201A | 45-80 | 20-40 | 7.5-8.5 | <3.0 | Good Flexibility | CNSL Modified Phenolic Resin | |
| PF-6533 | 50-90 | 20-40 | 8.5-9.5 | <1.0 | Good Flexibility | Special Modified Phenolic Resin | |
| PF-6443 | 40-90 | 25-40 | 8.5-9.5 | 1.0-5.0 | Good Flexibility | Special Modified Phenolic Resin | |
| PF-6530A | 60-90 | 33-53 | 3.0-9.0 | <2.5 | Good Flexibility | Special Modified Phenolic Resin | |
| Grade | Appearence | Viscosity@ 25 ℃(cp) | Free Phenol (%) | Solid Content (%) | Free Formaldehyde (%) | Application | Type |
| PF-6560 | Red-Brown Liquid | 600-800 | 14-18 | 68-74 | 0-1.0 | Alcohol Soluble Resin for Clutch | Liquid Phenolic Resin for Wetting Method Friction System |
| PF-6573 | Red-Brown liquid | 250-350 | 4-7 | 64-67 | 0-1.5 | Water Soluble Resole Resin | Liquid Phenolic Resin for Wetting Method Friction System |
| Grade | Appearence | Viscosity@ 25 ℃(cp) | Solid Content(%) | Application | Type | ||
| CP-2 | Brown Liquid | 18000-28000 | ≥95 | Flexible Friction Materia | Resin for Fiexibility Friction Material | ||
| Grade | Solid Content(%) | Viscosity@ 25 oc(cp)℃ | Application: | Type | |||
| PF-6900 | 33-38 | 10-14 | Binder for Brake Pads | Back Plate Adhesive | |||
| PF-6901 | 34-38 | 2000-5000 | Binder for Brake Linings and Motorcycles | Back Plate Adhesive |
Applications
SQ resin is applied to the production of brake linning,brake pad, brake shoes, train block, clutch facing and seal-materials.
Product Series
 |
|
 |
 |
| Phenolic Resin-for Friction Material | Cnsl Modified Phenolic Resin | Special Modified Phenolic Resin | Liquid Resin for Friction Material |
